K-POWER K-AX12 1.5N high torque TTL humanoid robot servo with feedback for education

FOB Reference Price:Get Latest Price
$14.00 - $25.00 / Pieces | 5 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Vacuum Cleaner Parts
Brand Name:
K-POWER
Model Number:
K-AX12
Stall torque:
1.5N/m (at 12V)
Communication proposal:
Half duplex Asynchronous Serial Communication
Link (physical):
TTL bus connection
Operation speed:
59rpm/12V
Operating travel:
0~300°
Size:
32mm x 50mm x 40mm
Weight:
60g
Application:
Smart home, Farm Machines, Humanoid robot, Bionic robots
Supply Ability
Supply Ability:
500000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Standard Package. Also can depend on your demands.
Port
Shenzhen, Guangzhou, Hongkong
Lead Time :
7-25 days after payment received
Product Details

K-POWER K-AX12 1.5N high torque TTL humanoid robot servo with feedback for education:


> Position, Temperature, Load, Input Voltage, etc. feedback
> TTL proposal
> With anti-slip function

Product Parameters
Model Type
K-AX12
Weight
60g
Size
32mm * 50mm * 40mm
Reduction ratio
254:1
Operation Voltage
9 ~ 12V
Stall torque
1.5N/m (at 12V)
Stall current
1.5A (at 12V)
Idle current
50mA
Operation temperature
-5℃ ~ +70℃
Operation speed
59rpm (at 12V)
Operating travel
Actuator Mode : 300°
Wheel Mode : Endless turn
Revolution
0.088°
Position sensor
ALPS potentiometer
Command signal
Digital Packet
Communication proposal
Half duplex Asynchronous Serial Communication(8bit,1stop,No Parity)
Link (physical)
TTL bus connection
ID
254 ID (0~253)
Baud Rate
9600 ~ 2M
Feedback
Position, Temperature, Load, Input Voltage, etc.
Application:
Humanoid Robot and Farm Machines
Service
Lifetime Warranty. Customized and OEM are available.
Any requirement, please feel free to tell us.
Customized the service for you! Thanks!
Product Details Show
Why Choose Us

About us

1, K-POWER is a professional servo manufacturer with over 13 years’ experience in China.

R & D

2, Professional & Department can provide the supports of constructional design and software.

Service

3, stable product quality , supply, the good faith management

Product Processing
Product Packing
FAQ

Q: What about the Warranty Procedure?
A: As long as you choose to use K-power products, you can enjoy the warranty service that we provide. All K-power products are warranted against defects for a period of one (1) years from the date of purchase. During this period we will repair or replace (at our discretion) any defective products. You should always retain your original receipt as proof of the date of purchase. Please print our Repair Request Form (.PDF, .DOC) and fill it out in its entirety, being as comprehensive as possible, in order to receive the best possible service.


Q: Can I get a free sample?
A: Some servos support free sample. Please contact with us for more detailed information.


Q: What is your servo's rotation angle?
A: The rotation angle can be adjusted according to your requirements, but it is 0~120 degree if no requirement, please do contact with us if you need special rotation angle.

Q: What is your servo's communication?
A: PWM, TTL, RS485 are optional. most of servo are PWM if no requirement, please do contact with us if you need not PWM.

Q: Can I get customized servo?
A: Of course! we have an excellent and Professional R&D Department, providing the supports for both constructional design and software. Perfect customization services are our main business.
We are confident we can make any to suit your application!

Q: For a customized servo, how long is the R&D time (Research & Development time)?
A: Normally, 10~50 business days depends on your requirements.


Contact us

Any questions, please contact us directly.We will reply you at the first time !
Tel: +86-13264692507
WeChat/QQ: 923959926

E-mail: sales07(@)rc-kpower.com
And welcome to our website http://www.rc-kpower.com


 High Quality! Good Price! Perfect Service!
  Catch us! Rest assured that the work to us!
This is Kyra for your service!
